Mini Managed Ethernet Switch 8 Port 1000T 802.3at PoE + 2 Port 1000X SFP

Name: Mini Managed Ethernet Switch 8 Port 1000T 802.3at PoE + 2 Port 1000X SFP
Brand: E-link
SKU: LNK-IMC208SGP-SFP
Price: 99 USD
Availability: InStock
Rating: 4.6 (164 reviews)

Large Image : Mini Managed Ethernet Switch 8 Port 1000T 802.3at PoE + 2 Port 1000X SFP

Product Details:

Place of Origin:	China
Brand Name:	E-link
Certification:	CE
Model Number:	LNK-IMC208SGP-SFP

Payment & Shipping Terms:

Minimum Order Quantity:	1pcs
Price:	USD99/PCS
Packaging Details:	Standard Carton Packaging
Delivery Time:	3-5 working days
Payment Terms:	L/C, T/T, Western Union
Supply Ability:	1000000PCS/Month

Contact Now

Detailed Product Description

Product Name:	Mini Industrial 8GE+2SFP PoE Switch	Backplane Bandwidth:	20Gbps
Packet Buffer Memory:	9216 Bits	Max Packet Length:	9K Bytes Jumbo Frame
Connector:	8 X RJ45	Optical Port:	2 X 100/1000Base-X SFP
PoE Budget:	Up To 240-watt PoE Budget	Input Power:	48~57VDC
Dimensions (WxDxH):	95 X 88 X 46 Mm	Weight:	0.3Kg
High Light:	Mini Managed Ethernet Switch FCC , 20Gbps Managed Ethernet Switch

Mini Industrial Managed 8-Port 10/100/1000T 802.3at PoE + 2-Port 100/1000X SFP Ethernet Switch

Product Description

Overview

LNK-IMC208SGP-SFP, a managed industrial network switch, with an 8 ports 10/100/1000Base-TX + 2 port 100/1000Base-X SFP. The Switch provides 8 port PoE+ function for kinds of Powered Devices to receive power as well as data over the RJ-45 cable. The 100/1000Base-X SFP supports 1 or 2 core Single-mode or Multi-mode fiber. With its reliable design and ease of use, the product is a great choice for integrating networks consisting of network devices such as IP cameras and wireless access points between remote locations.

Features

8x10/100/1000Base-TX + 2x100/1000Base-X SFP
10/100/1000Mbps RJ45 Port Supports Full/Half-duplex, Auto-negotiation, Auto MDI/MDIX
Supports WEB Management
Supports IEEE 802.3at PoE+ (30W per port)
Supports 802.3x Flow Control
Support IEEE802.3/802.3u/802.3ab/802.3z/802.3x store and forward mode
Support IEEE 802.3D/W/S standard STP/RSTP protocol
IEEE 802.3az Energy Efficient Ethernet (EEE)
Redundant Power Inputs
Supports DIN-Rail installation
-40°C to 80°C (-40°F to 176°F) operating temperature.

Technical Indexes

Ethernet
Backplane bandwidth	20Gbps
Packet Buffer Memory:	9216 bits
Processing Type:	Store-and-Forward
Max Packet Length:	9K Bytes Jumbo Frame
Address Table Size:	4K MAC Addresses
Interface
Connector:	8 x RJ45
Optical Port:	2 x 100/1000Base-X SFP
PoE (Power over Ethernet)
Power Pin Assignment	4/5(+), 7/8(-)
PoE Budget:	Up to 240-watt PoE budget
Environmental
Operating Temperature:	-40°C to 80°C (-40°F to 176°F)
MTBF	> 200,000 hrs
Electrical and Mechanical
Input Power:	48~57VDC, Redundant Power (4-pin Terminal Block)
Power Consumption:	5W Max.(PoE in Use<240W)
Protection:
Power Input Overload:	Automatic Resettable
Reverse Polarity:	Present
Software Features
Redundancy Protocols	Support STP/RSTP
Multicast Support	Support IGMP Snooping V1/V2/V3
VLAN	Support IEEE 802.1Q 4K VLAN
QOS	Support Port, 1Q, ACL, DSCP, CVLAN, SVLAN, DA, SA, Port Priority, Queue Weight
Diagnostic Maintenance	Support port mirroring, Syslog, Ping
Management Function	WEB
Security	Broadcast/Multicast Storm Protection, MAC filtering, MAC Constraint
