16-Port Gigabit PoE Injector IEEE 802.3af/at Mid-span Power Supply

Large Image : 16-Port Gigabit PoE Injector IEEE 802.3af/at Mid-span Power Supply

Product Details:

Place of Origin:	Guangdong, China
Brand Name:	E-link
Certification:	CE, FCC, RoHS, ISO9001
Model Number:	LNK-POE216/LNK-POE316
Document:	2E-link Video Transmission ...og.pdf

Payment & Shipping Terms:

Minimum Order Quantity:	1 pcs
Price:	$130-$200
Packaging Details:	PoE Injector Standard Export Package
Delivery Time:	3-7 working days
Payment Terms:	T/T,Western Union,MoneyGram
Supply Ability:	1000 pcs/month

Contact Now

Detailed Product Description

PoE Standard:	IEEE 802.3af (15.4W), IEEE 802.3at (30W)	Ports:	32 × 10/100/1000M RJ45 (16 Uplink + 16 PoE Output)
Data Rate:	10/100/1000Mbps	Input Power:	90–240V AC, 50–60Hz
Cooling:	Fanless, Natural Heat Dissipation	Use Case:	IP Cameras, APs, VoIP, Security & Enterprise Networks

16-Port Gigabit PoE Injector IEEE 802.3af/at Mid-span Power Supply

Overview

The 16-Port PoE Injector is a high-performance mid-span power solution designed to

deliver reliable power and data over a single Ethernet cable. With support for IEEE

802.3af/at standards, it provides up to 30W per port, making it ideal for powering IP

cameras, VoIP phones, wireless APs, and other PoE-enabled devices. Its fanless design

ensures quiet operation and easy deployment in offices, surveillance, and enterprise

networks.

Features

16 PoE Ports delivering power and data simultaneously via Cat5/5e/6 cables.

IEEE 802.3af/at compliant, supporting up to 30W per port.

Dual RJ45 design: uplink port + PoE output port for flexible connectivity.

Natural cooling with fanless, silent operation for office and industrial use.

Wide AC input (90–264V) ensures global adaptability.

Rackmount size for easy integration into existing networks.

Technical Indexes

Parameter	Specifications
Features	Conforms to IEEE802.3af standard RJ-45 Conforms to IEEE802.3af standard RJ-45
	Data Input Interface 16RJ-45 10/100Base-TX/ Data Input Interface 16RJ-45 10/100/1000Base-TX
	Output Port Power Cable Included
Data Rate	10/100Mbps 10/100/1000Mbps
Input Power	90-240V AC ,50-60Hz
Output Power	1615.4W Max IEEE802.3af 1630W Max IEEE802.3at
Wiring	Data provide over pairs 1/2(+) and 3/6(-)
Wiring	Power over spare pairs 4/5(+) and 7/8(-)
LED Display	YES
Operating Temperature	0 to +40°C,
Humidity	Max. 95% RH(non-condensing)
Dimension	445X260X45(H×D×W)
Weight	5.5KG

Ordering Information

Model	Decription
LNK-POE216	16-port PoE Adapter, 10/100Mbps, IEEE 802.3af 15.4W
LNK-POE216AT	16-port PoE Adapter, 10/100Mbps, IEEE 802.3at 30W
LNK-POE316	16-port PoE Adapter, 10/100/1000Mbps, IEEE 802.3af 15.4W
LNK-POE316AT	16-port PoE Adapter, 10/100/1000Mbps, IEEE 802.3at 30W
