PCIe x4 Single Port 10G Ethernet network adapter
10G Ethernet network adapter Overview
The LNK-C6880BT is a high-performance, single-port, 10-Gigabit Ethernet PCIe network adapter
designed for demanding client systems. Built on the advanced Aquantia AQC107 chipset,
the LNK-C6880BT delivers exceptional network speeds of 10 Gbps, 5 Gbps, 2.5 Gbps, 1 Gbps,
and 100 Mbps over standard Cat5e, Cat6, and Cat6a cabling. It offers a future-proof upgrade
path that does not require expensive infrastructure changes.
The PCIe x4 universal interface ensures broad compatibility with x4, x8, and x16 motherboard
slots for flexible installation. Key features such as MSI/MSI-X interrupts, receive-side scaling (RSS),
and TCP/UDP checksum offloading significantly reduce CPU overhead, enabling high-throughput
data transfers with minimal system impact. Ideal for professionals in content creation, data analysis,
and gaming, this card provides powerful, space-efficient, and reliable connectivity.
10G Ethernet network adapter Features
- Cost-effective, low-power, and energy-efficient Ethernet solution
- Supports multiple data rates: 100M / 1Gbps / 2.5Gbps / 5Gbps / 10Gbps
- Jumbo frame support up to 16 KB
- Broad software compatibility: Windows & Linux drivers, UEFI, PXE remote boot
- PCI Express (PCIe) v3.0, x4 lanes for high-performance connectivity
- Advanced features: MSI, MSI-X, LSO, RSS, IPv4/IPv6 checksum offload
10G Ethernet network adapter Specifications
|
Controller
|
AquantiaAQtion AQC107
|
|
Transmission medium
|
Copper
|
|
Copper Type
|
10GBase-T:Cat 6 or higher up to 100m
|
|
5GBase-T:Cat 6 or higher up to 100m
|
|
2.5GBase-T:Cat 5e or higher up to 100m
|
|
1GBase-T:Cat 5e or higher up to 100m
|
|
100MBase-T:Cat 5 or higher up to 100m
|
|
Baffle Height
|
Half & Full height
|
|
Power Consumption
|
4.7W
|
|
OS Support
|
Windows 7/8/8.1/10
|
|
Windows Server 2008 R2 /2012 R2 /2016 R2 /2019 R2
|
|
Linux Stable Kernel version 2.6.32/3.x/4.x or later
|
|
Linux CentOS/RHEL 6.5 / 7.x or later
|
|
Ubuntu 14.x/15.x/16.x or later
|
|
VMware ESX/ESXi 4.x/5.x/6.x or later
|
|
Bus Type
|
PCIe v2.1 x4 ,compatible with x8 , x16
|
|
Data rate per port
|
100/2500/5000/10000Mbps
|
|
Connector
|
1*10G RJ45
|
10G Ethernet network adapter Technical Features
|
Standards compliant
|
IEEE 802.3an 10 Gbit/s Ethernet over unshielded twisted pair IEEE 802.3bz 2.5/5GBASE-T
IEEE 802.3ab 1000BASE-T Gigabit Ethernet IEEE 802.3u 100BASE-TX Fast Ethernet
IEEE 802.1Q VLANs
IEEE 802.3x Full Duplex and flow contro
IEEE 802.3az - Energy Efficient Ethernet (EEE)
|
|
iSCSI
|
No
|
|
WoL
|
No
|
|
Jumbo Frames
|
Yes
|
|
DPDK
|
Yes
|
|
PXE
|
Yes
|
|
FCoE
|
No
|
