10/100M Fast Ethernet Media Converter with SFP Slot External Power

Large Image : 10/100M Fast Ethernet Media Converter with SFP Slot External Power

Product Details:

Place of Origin:	Guangdong, China
Brand Name:	E-link
Certification:	CE, FCC, RoHS, ISO9001
Model Number:	LNK-1100WSFP
Document:	1E-link Communication & Net...og.pdf

Payment & Shipping Terms:

Minimum Order Quantity:	1 PCS
Price:	$11-$20
Packaging Details:	Ethernet Media Converter Standard Export Package
Delivery Time:	3-9 working days
Payment Terms:	T/T,Western Union,MoneyGram
Supply Ability:	1000 pcs/month

Contact Now

Detailed Product Description

Network Interface:	1 × RJ45 (10/100Mbps), 1 × SFP (100Base-FX)	Transmission Distance:	100m Copper, 2 Km Multi-mode Fiber, 20–120 Km Single-mode Fiber
Power Supply:	External AC90–264V/DC100–380V → 5V1A	Power Consumption:	5W
Operating Temp:	-10°C To 55°C, Storage: -40°C To 70°C	Compliance:	IEEE802.3, IEEE802.3u, IEEE802.3x

10/100M Fast Ethernet Media Converter with SFP Slot External Power

Overview

The LNK-1100WSFP is a versatile Fast Ethernet media converter that connects copper and

fiber networks via RJ45 and SFP interfaces. Designed for long-distance transmissions up to

120 km, it supports full/half-duplex, auto MDI/MDI-X, VLAN packet transmission, and QoS

for VoIP applications. External power supply ensures reliable industrial operation.

Features

Dual media support – 10/100Base-TX RJ45 to 100Base-FX SFP slot

Long-distance transmission – up to 120 km via fiber

Flexible operation – auto-sense full/half duplex, MDI/MDI-X

Enhanced performance – supports extra-long VLAN packets and QoS

Reliable & industrial – external AC/DC power supply with low 5W consumption

Status LEDs – power, TP/fiber link & activity, full duplex indicators

Compact & durable – lightweight with wide operational temperature

Technical Indexes

Parameter	Specifications
Access mode	10/100Mbps Fast Ethernet
Standard	IEEE802.3 10Base-T Ethernet, IEEE802.3u,100Base-TX/FX Fast Ethernet, IEEE802.3x Flow control
Wavelength	850nm/1310nm/1550nm
Transmission distance	multi-mode Dual-fiber: 2KM
	single mode Dual-fiber: 20/40/60/80 Km
	single mode Single fiber: 20/40/60/80 Km
	Category-5 twisted pairs: 100m
Port	One RJ45 port: for connecting with STP/UTP category-5 twisted pairs
Port	One optical port: SFP 3.3V
Conversion means	Media conversion
BER	<10-9
MTBF	100,000 hours
LED indicator	POWR (power supply); FX LINK/ACT (optical link action); FDX (FX full duplex), TX LINK/ACT (TP cable link/action); TX 100 (TP cable rate 100M), FX100(fiber cable rate 100M)
Power supply	External Power: AC90~264V/DC100~380V input, 5V1A output
Power consumption	5W
Operating temperature	-10~55ºC
Operating humidity	5%~90%
Maintaining temperature	-40~70ºC
Maintaining humidity	5% ~ 90% non-condensing
