7 Port PoE Switch Extends Power & Data 200m

Industrial Managed Switch
December 25, 2025
Category Connection: Industrial Managed Switch
Chat Now Contact Us
Tags:
#industrial grade ethernet switch #industrial gigabit ethernet switch #industrial grade network switch
Brief: In this video, we demonstrate how the Industrial 7-Port PoE Powered Gigabit Switch with PoE Passthrough SFP extends both power and data up to 200 meters. Watch as we show its PoE passthrough technology in action, eliminating the need for rewiring in remote locations. You'll see how this compact industrial switch powers IP cameras, wireless APs, and edge devices in harsh environments with its rugged design and flexible fiber uplink options.
Related Product Features:
  • PoE Passthrough design with 1x IEEE 802.3bt PoE++ input and 4x PoE outputs delivering 71W total budget.
  • Dual 100/1000X SFP slots provide flexible fiber uplink options for long-distance networking.
  • Extends PoE transmission distance from 100m to 200m, doubling standard reach capabilities.
  • Rugged IP40 aluminum case with fanless design and DIN-Rail mounting for harsh industrial environments.
  • Operates reliably across wide temperature range from -40°C to 80°C for extreme conditions.
  • Plug-and-play installation powered via PoE injector or switch without needing AC adapter.
  • Compact 95x88x46mm design with 300g weight for space-constrained installations.
  • Compliant with industrial standards including CE, FCC, RoHS and ISO9001 certifications.
FAQs:
  • How does the PoE passthrough feature work and what are its benefits?
    The switch features 1x IEEE 802.3bt PoE++ input port that receives up to 95W power, which it then distributes through 4x PoE output ports with 71W total budget. This eliminates the need for separate power wiring at remote locations, reducing installation costs and extending network reach up to 200 meters.
  • What types of environments is this industrial switch suitable for?
    Designed for harsh industrial environments, this switch features an IP40-rated aluminum case, fanless design, DIN-Rail mounting, and operates reliably from -40°C to 80°C. It's ideal for surveillance systems, wireless access points, and edge devices in challenging outdoor or industrial settings.
  • Can this switch be used for long-distance network connections?
    Yes, the switch includes dual 100/1000X SFP slots that support fiber optic connections for flexible long-distance networking. Depending on the SFP module used, it can support distances from 2km up to 120km, making it perfect for extending networks across large facilities or between buildings.
