Industrial Device Server 4 Port RS232 RS485 Ethernet Converter with ESD Protection

4Ch RS-232/422/485 To Ethernet Server

 4Ch to Ethernet Server Overview

The LNK-NC604 Serial Device Server enables seamless integration of industrial serial equipment into modern Ethernet networks. It converts RS232, RS422, and RS485 serial interfaces to 10/100M Ethernet, allowing centralized management and remote access to distributed serial devices and host computers through standard IP networks.

This robust device supports a comprehensive suite of network protocols including HTTP, TCP, UDP, ARP, ICMP, DNS, and DHCP, ensuring reliable communication across diverse network environments. It features Windows Native COM port support with automatic recovery functionality that reestablishes connections after network interruptions.

For flexible configuration, the LNK-NC604 provides multiple management options through a dedicated Windows-based utility and an intuitive web interface. These tools guide administrators through device setup, monitoring, and maintenance processes. All configurations can be performed remotely via network or locally through serial connection, with support for gateway and router traversal. Users can easily define IP addresses, select between Server and Client operation modes, and adjust data packet sizes according to application requirements.

With minimal setup, the LNK-NC604 quickly brings traditional serial devices online, creating an efficient bridge between legacy equipment and contemporary network infrastructure for immediate internet connectivity.

4Ch to Ethernet Server Features

• Full TCP/IP Protocol Suite Compliance
  Engineered for seamless network integration, the device strictly adheres to international TCP/IP standards, ensuring reliable data packet delivery and full interoperability with existing network infrastructure and management systems.
• Auto-Negotiating Fast Ethernet Port
  Features a 10/100Mbps auto-MDI/MDIX Ethernet interface that automatically detects and negotiates network speed and duplex mode, eliminating the need for crossover cables and simplifying plug-and-play installation.
• High-Density Multi-Protocol Serial Hub
  Integrates four independent serial ports, each universally compatible with RS-232, RS-422, and RS-485 standards. This design provides a centralized access point for numerous serial devices from a single network node.
• Robust Serial Line Protection
  All serial signal lines are equipped with built-in 15 kV ESD (Electrostatic Discharge) surge protection, safeguarding connected equipment from voltage spikes and transients to ensure operational stability in harsh industrial environments.
• Versatile Data Transport Modes
  Supports an extensive range of operational modes including TCP Realport, UDP Realport, Multi-screens TTY, PPP dial-out, Line printer daemon, MCP, and Group Realport, offering flexibility for diverse application requirements.
• Dual-Access Management Interface
  Offers administrators flexible configuration options through both Telnet for command-line control and an intuitive Web browser interface for graphical user management, facilitating easy local or remote setup.
• Flexible Wide-Range Power Input
  Designed with a versatile wide-range DC power input (5/12/24/48V), making it adaptable to various industrial power standards and environments, from low-voltage control panels to telecom installations.
• Compact Industrial Form Factor
  Housed in a compact and rugged metal enclosure with dimensions of 160mm (L) x 89mm (W) x 29mm (H), engineered for space-efficient deployment on DIN rails or in control cabinets.

4Ch to Ethernet Server Technical Indexes

4Ch to Ethernet Server Ordering Information

4Ch to Ethernet Server Application

The LNK-NC604 Device Server is a pivotal Network Access Terminal designed for integrating Legacy Serial Equipment into modern Fiber Optic Ethernet Backbones. It acts as a Protocol Conversion Gateway, enabling Real-Time Data Aggregation and Remote Telemetry from dispersed industrial assets.

A primary application is within Industrial Automation Networks, where it facilitates Centralized SCADA Monitoring and Remote PLC Management by converting Multi-Protocol Serial Signals (RS-232/422/485) from devices like CNC Controllers, Bar Code Scanners, and Sensor Arrays into Standard TCP/IP Ethernet Frames. This allows for Long-Distance Data Transmission over Gigabit Fiber Optic Links, overcoming the limitations of traditional copper serial cabling.

Furthermore, it is ideal for building resilient IoT Gateway Solutions in Smart City Infrastructure and Telecommunications Transmission Networks. It enables Network Operation Centers (NOC) to monitor and manage Optical Transmission Equipment, Remote Terminal Units (RTU), and Network Switches via console ports. Its robust design, featuring 15kV ESD Surge Protection and Wide-Range DC Power Input, ensures reliability in electrically harsh environments. Support for cross-network communication via Gateway Traversal allows for the creation of Secure, Distributed Data Acquisition Networks, streaming Telemetry Data seamlessly across Wide Area Networks (WAN) to central OSS/BSS Platforms and Cloud Management Systems.
