8 Port 10/100/1000BASE-T + 2 Port 1000BASE SFP Auto-sensing IEEE 802.3af/at POE/POE+ and 24V passive POE Switch
Unmanaged PoE Switch Overview
The LNK-A208GP-SFP is a high-performance 8-port Gigabit Power over Ethernet switch
featuring 4 x 10/100/1000Base-TX RJ45 ports with dual power options (IEEE 802.3af/at Power over
Ethernet Plus and 24V Passive Power over Ethernet) and 2 x 1000Base-FX SFP fibre slots
for 1G uplinks. This plug-and-play switch has been designed for IP surveillance
and wireless deployments. It ensures stable power delivery and long-distance fibre connectivity,
making it perfect for remote IP cameras, WiFi APs and industrial networks.
Unmanaged PoE Switch Features
- Auto-sensing IEEE 802.3af/at PoE/PoE+ and 24V passive PoE support
- 10/100/1000 Mbps, full/half-duplex, auto-negotiation, Auto MDI/MDI-X
- One external 1000Base SFP slot for fiber uplink expansion
- Comprehensive protection features: overcurrent, short-circuit, over-voltage, under-voltage,
- power limitation, and Hi-Power PD safe function
- Automatically distinguishes between Active PD and Passive PD devices
- Total PoE power budget up to 150W
- Flexible installation options: wall-mount or desktop/shelf mounting
Unmanaged PoE Switch Technical Indexes
|
Ethernet & Fiber
|
|
Standards
|
IEEE802.3 10Base-T
|
|
IEEE802.3u 100Base-TX
|
|
IEEE802.3ab 1000Base-T
|
|
IEEE802.3z 1000Base-X (Fiber)
|
|
IEEE802.3x Flow Control
|
|
IEEE802.1q VLAN Bridge Operation
|
|
IEEE802.3af Power over Ethernet
|
|
IEEE802.3at Power over Ethernet
|
|
Processing Type
|
Store-and-Forward (2.5M cache)
|
|
System Mode
|
Standard/VLAN Isolation
|
|
Switch Fabric
|
20 Gbps
|
|
MAC address
|
8K
|
|
Forward Filter Rate
|
14,880pps (10Mbps)
|
|
148,800pps (100Mbps)
|
|
1,488,000pps (1000Mbps)
|
|
Ethernet Port
|
8 x 10/100/1000Mbps RJ45 Ethernet Ports
|
|
Optical Port
|
2 x SFP 1000Base-FX
|
|
Electrical and Mechanical
|
|
Input Power (AC/DC 2 power)
|
48~57VDC or 100~265VAC 50/60Hz
|
|
Power Consumption
|
20W Max. (PoE not in use)
|
|
150W Max. (PoE in use)
|
|
LED Indicators
|
|
Power
|
Power Status
|
|
9-10
|
Port Fiber
|
|
PoE Green
|
48V PoE
|
|
PoE Orange
|
24V PoE
|
|
Link Orange
|
1000M Speed
|
|
Link Green
|
10/100M Speed
|
|
PoE
|
|
Standard
|
IEEE802.3af/at
|
|
Port
|
RJ45 Port1~Port4
|
|
Max. Power per port
|
30W Max per port (Alternative B mode)
|
|
PoE Output Auto-sensing
|
Support both Active and Passive PD without setting
|
|
PoE Interfaces
|
PoE+ IEEE 802.3af/at (Pins 1, 2+; 3, 6-)
24VDC Passive PoE (Pins 4, 5+; 7, 8-)
|
|
Function
|
Support Overcurrent, Shortcurrent, OverVOL, UnderVOL, Power Limitation, Safe Function HiPower PD star BOOT, After Boot
|
|
Mechanical
|
|
Dimensions (L x W x H)
|
210 x 140 x 45 mm
|
|
Weight
|
1.5Kg
|
|
Casing
|
Metal Case
|
|
Mounting options
|
Wall-mount and desk/shelf mounting
|
|
Environmental
|
|
Operation Temperature
|
0°C to 40°C (32°F to 104°F)
|
|
Storage Temperature
|
-40°C to 70°C (-40°F to 158°F)
|
|
Relative Humidity
|
5% to 90% non-condensing
|
|
MTBF
|
> 200,000 hrs
|
|
Regulatory Approvals
|
|
ISO9001,CE, FCC, RoHS
|
Unmanaged PoE Switch Ordering Information
|
Model
|
Description
|
|
LNK-A208GP-SFP
|
Auto-sensing IEEE 802.3af/at PoE/PoE+ and 24V passive PoE Switch: 8-Port 10/100/1000BASE-T + 2-Port 1000BASE SFP
|
|
SFP Options
|
► SFP option. Please select your SFP on our SFP Options Page
|
|
► SFP module is to be purchased separately.
|
|
Mounting Options
|
► Wall-mount and desk/shelf mounting
|
Unmanaged PoE Switch Application
