4 RJ45 Port Industrial Gigabit Ethernet POE Switch IEEE802.3 Standards

China 4 RJ45 Port Industrial Gigabit Ethernet POE Switch IEEE802.3 Standards supplier

Large Image :  4 RJ45 Port Industrial Gigabit Ethernet POE Switch IEEE802.3 Standards

Product Details:

Place of Origin: Standalone Web-Smart 10G OEO Converter 3R Repeater SFP+ to SFP+ Product Description 10G OEO Converter-3R SFP+-SFP+ 1.jpg10G OEO Converter-3R SFP+-SFP+ 2.jpg Model: LNK-OEO-SS Overview E-link Standalone 10G OEO Converter (3R Repeater) with SFP+ to SFP
Brand Name: E-link
Certification: CE/FCC/Rohs
Model Number: LNK-IMC1400GP-SFP

Payment & Shipping Terms:

Minimum Order Quantity: 1 piece
Price: Negotiation
Packaging Details: 1 piece in 1 carton box
Delivery Time: 5-8 days
Payment Terms: T/T, L/C, Western Union, MoneyGram
Supply Ability: 1000000000pcs/Month
Contact Now
Detailed Product Description
Processing Type: Store-and-Forward Packet Buffer Memory: 1M Bits
Max Packet Length: 9K Bytes Jumbo Frame Address Table Size: 2048 MAC Addresses
Input Power: 2x48~57VDC Port: RJ45 Port 1 ~ Port 4

4-port 10/100/1000BASE-T + 1-port 1000BASE SFP Industrial Ethernet PoE Switch

Model: LNK-IMC1400GP-SFP Series

Overview

he LNK-IMC1400GP-SFP product is a Self-Configured Hardened Ethernet switch which provides 4 port 10/100/1000Base-TX + 1x1000Base-FX SFP port. The 10/100/1000Base-TX ports supports PoE+ (Power Sourcing Equipment) and compliant with IEEE 802.3at.

Comply with IEEE 802.3 10Base-T, IEEE802.3u 100Base-TX/FX, IEEE 802.3x, and IEEE802.3at. The product will provide PoE power to any IEEE802.3at/af compliant network device. It supports IGMP snooping which significantly saves the network bandwidth and reduces network load. With its reliable design and ease of use, the product is a great choice for integrating networks consisting of network devices such as IP cameras and wireless access points between remote locations.



Features

  • Automatically support IGMP (Multicasting)
  • Supports 10/100/1000Mbps-Full/Half-duplex,
  • Auto-negotiation, Auto MDI/MDI-X
  • Supports external 1000BASE SFP
  • Supports Daisy-Chain connection
  • Supports IEEE 802.3at PoE+(30W per port)
  • Supports Light Hardware IGMP V1, V2, V3
  • Supports Broadcast Storm Control
  • Supports Relay output for power failure
  • 1M bits frame buffer memory
  • Supports 9K Bytes Jumbo Frame
  • Supports the transmission of extra-long VLAN packets
  • Supports Quality of Service (QoS) and ensuring the transmission of VoIP packets;
  • Supports Energy Efficient Ethernet IEEE802.3az
  • Redundant Power Inputs
  • Supports Wall-mount and DIN-Rail installation
  • Environmentally hardened -40°C to 80°C
    (-40°F to 176°F) operating temperature

Warranty

  • 5-Year Warranty



Technical Indexes

Ethernet
Standards: IEEE802.3 10BASE-T
IEEE802.3u 100BASE-TX/FX
IEEE802.3ab 1000BASE-T
IEEE802.3z 1000BASE-X
IEEE802.3q VLAN
IEEE802.3p QoS
IEEE802.1d Spanning Tree
IEEE802.3af Power over Ethernet
IEEE802.3at Power over Ethernet
Forward & Filtering Rate: 14,880pps (10Mbps)
148,800pps (100Mbps)
1,488,000pps (1000Mbps)
Packet Buffer Memory: 1M bits
Processing Type: Store-and-Forward
Max Packet Length: 9K Bytes Jumbo Frame
Address Table Size: 2048 MAC Addresses
Connector: 4 x RJ45
Optical Port: 1 x SFP 1000Base-X
Environmental
Operating Temperature: -40°C to 80°C (-40°F to 176°F)
Storage Temperature: -40°C to 85°C (-40°F to 185°F)
Relative Humidity: 5% to 95% non-condensing
Electrical and Mechanical
Input Power: 2x48~57VDC (Terminal Block)
Power Consumption: 135W Max. 2.8A@48VDC (PoE in use)
5W Max. 0.1A@48VDC (PoE not in use)
Standard: IEEE802.3at
PoE:
Port: RJ45 Port 1 ~ Port 4
Max. Power per Port: 30W Max per port (Alternative B Mode)
Protection:
Power Input Overload: Automatic Resettable
Reverse Polarity: Present
LED Indicators:
Power: Power Status
Ethernet(Per Port): Link/Activity
SFP: Link/Activity
Dimensions (WxDxH): 148 x 120 x 31 mm
Weight: 0.5Kg
Casing: Metal Case
Mounting Options: DIN-Rail / Wall-mount
Regulatory Approvals
ISO9001
EN55022 Class A, FCC part 15 Class A
Surge Protection:
RJ45: 1KV
Power: 500W
