10 / 100 / 1000M Multimode POE Fiber Media Converter With 15.4w Internal Power

10 / 100 / 1000M Multimode POE Fiber Media Converter With 15.4w Internal Power
10 / 100 / 1000M Multimode POE Fiber Media Converter With 15.4w Internal Power 10 / 100 / 1000M Multimode POE Fiber Media Converter With 15.4w Internal Power

Large Image :  10 / 100 / 1000M Multimode POE Fiber Media Converter With 15.4w Internal Power

Product Details:
Place of Origin: Guangdong, China
Brand Name: E-link
Certification: CE/FCC/Rohs
Model Number: LNK-POE1000-SC-M005
Payment & Shipping Terms:
Minimum Order Quantity: 1
Price: Negotiation
Packaging Details: Standard export package
Payment Terms: T/T, Western Union, MoneyGram
Detailed Product Description
PoE Standard: IEEE802.3af (15.4W) Data Rate: 10/100/1000M
Fiber Type: Multi-mode Distance: 550m
Connector: RJ45 / SC Power Supply: AC 100-240V
High Light:

single mode fiber media converter

,

poe powered media converter

10/100/1000Mbps Multi-mode 550m 15.4w PoE Media Converters with Internal Power

Model: LNK-POE1000-SC-M005

Overview



LNK-POE1000 series is a 10/100/1000Base-TX to 1000Base-FX (also can be forced to 100Base-FX) media converter, which allows two types of network segment to be connected easily. Complied with IEEE802.3at or IEEE802.3af standard, the AC/DC powered PoE media converter is a Power Sourcing Equipment (PSE) which combines data transfered over a fiber optic link with 48V (or other voltage) power supply, providing power to IEEE802.3at or IEEE802.3af powered device (PD) over CAT5e/CAT6 UTP cable (cable length up to 100meters / 330feets). The converter includes a single port PSE controller, which offers PD signature sensing and power monitoring features. Other features include over-current protection, LFP function, etc. The LFP (Link Fault Pass-through) allows the media converter to monitor both the fiber and copper RX port for loss of signal. In case of a loss of RX signal on one media port, the converter will automatically disable the TX signal to the other media port, thus passing through the link fault.



Features

  • 10/100/1000Base-TX UTP to 1000Base-FX fiber media conversion
  • IEEE802.3at / IEEE802.3af PoE PSE compatible
  • Built-in AC/DC power supply
  • Over-current protection
  • Choice of SC, LC, BiDi or other connectors for multimode and singlemode
  • DIP switch to set different configurations
  • LFP (Link Fault Pass-through) support
Warranty: 2 Years


Technical Indexes



Data Rates 10/100/1000Mbps(IEEE802.3U IEEE802.3z 1000Base-Tx)
1000Mbps (1000Base-FX) or 100Mbps (100Base-FX)
Input Power Requirements
Input voltage 100 VAC to 240 VAC
Input frequency 47 Hz to 63 Hz
Power over Ethernet Output
Pin Assignment and Polarity
For IEEE802.3af standard 1/2 (V+),3/6 (V-)
For IEEE802.3at standard (30watts maximum) 1/2 (V+),3/6 (V-)
For IEEE802.3at standard (50watts maximum) 1/2/4/5 (V+),3/6/7/8 (V-)
Output Power please refer to ordering information
Efficiency 75% min
Short circuit protection auto recovery
Over current protection auto recovery
Environmental Conditions
Operating temperature 0 to 50℃
Cooling free air convection
Storage temperature -20 to +85℃
Operating Humidity 90% max, non-condensing
Mechanical Specifications
Case Material Iron
Case Color Black
Net Weight 560g approx. / unit
Dimensions 110(W) x 40(H) x 140(L) (mm)
Do not include transceiver length
Connectors
AC Inlet IEC-J-4
LAN Shielded RJ-45
Fiber see ordering information





Application



10 / 100 / 1000M Multimode POE Fiber Media Converter With 15.4w Internal Power 0
