95W Outdoor Industrial IP67 Waterproof 802.3at PoE+ Injector
Industrial IP67 Waterproof PoE Injector Overview
The E-Link LNK-IPOE-95W is an industrial-grade, IP67-rated, single-port PoE++ injector designed
for extreme outdoor use. It delivers a robust 95W of IEEE 802.3bt-compliant power alongside Gigabit
Ethernet data over standard UTP cabling. The E-Link reliably powers high-demand devices, such as
PTZ cameras, speed domes, and Wi-Fi 6 access points. Its rugged, IP67-rated aluminum housing offers
superior protection against dust, water immersion, and electromagnetic interference. It operates flawlessly
in extreme temperatures ranging from -40°C to 80°C. Advanced features include automatic PD detection
and classification, a wide voltage input range of 90–264 VAC, and a transmission distance of 100 m.
Designed for mission-critical applications in harsh environments, the E-Link LNK-IPOE-95W supports
easy installation with the LNK-POT-MBK mounting kit, eliminating the need for equipment modification.
Industrial IP67 Waterproof PoE Injector Features
-
Supports 10/100/1000Base-TX high-speed Ethernet connections
-
IEEE 802.3af/at/bt compliant for wide PoE compatibility
-
Designed for outdoor applications with direct power input
-
High-power PoE output up to 95W for demanding devices
-
Power pin assignments: 4/5 (+), 7/8 (-) and 1/2 (+), 3/6 (-)
-
Integrated data and PoE output with 6KV lightning protection
-
Wide operating temperature range: -40°C to +80°C (-40°F to +176°F)
-
Rugged IP67-rated metal enclosure, waterproof and dustproof
-
Sealing gasket tested for extension, load, corrosion, and aging resistance
-
Plug-and-play installation for fast and easy deployment
Industrial IP67 Waterproof PoE Injector Technical Indexes
|
Ethernet
|
|
Standards:
|
IEEE 802.3 10BASE-T Ethernet
|
|
IEEE 802.3u 100BASE-TX Fast Ethernet
|
|
IEEE 802.3ab 1000BASE-T Gigabit Ethernet
|
|
Processing Type:
|
Forward
|
|
Half-duplex, Full-duplex
|
|
Forward Filter Rate:
|
1,488,000pps (1000Mbps)
|
|
Cabling:
|
10/100/1000Base-T
|
|
Connector:
|
2x M22 Shielded RJ-45
|
|
Environmental
|
|
Operating Temperature:
|
-40°C to 80°C (-40°F to 176°F)
|
|
Storage Temperature:
|
-40°C to 85°C (-40°F to 185°F)
|
|
Relative Humidity:
|
5% to 95% non-condensing
|
|
MTBF:
|
>200,000hrs
|
|
Input & Output
|
|
Input Power:
|
90~264VAC
|
|
Output PoE Power:
|
55VDC 1750mA
|
|
Power Pins:
|
4/5(+),7/8(-) and 1/2(+),3/6(-)
|
|
PoE (Power over Ethernet)
|
|
Standard:
|
IEEE802.3af/at/bt
|
|
Port:
|
M22 Shielded RJ-45
|
|
Max. Power per Port:
|
95W Max
|
|
AC Surge Protection
|
|
Line-Earth 1.2/50us (8/20us):
|
6KV
|
|
Line-Line 1.2/50us (8/20us):
|
4KV
|
|
PoE Surge Protection
|
|
Protected line:
|
1,2,3,4,5,6,7,8
|
|
Common mode surge protection(10/700us):
|
6KV
|
|
Differential mode surge protection (10/700us):
|
1.5KV
|
|
Mechanical
|
|
Dimensions (LxWxH):
|
304 x 184 x 75 mm (inner size)
|
|
Weight:
|
3.6Kg
|
|
Casing:
|
Aluminum Case
|
|
Color:
|
Silver
|
|
Mounting Options:
|
Pole-Mount
|
|
Regulatory Approvals
|
|
Safety Approvals: UL, CE
|
|
EMI: FCC CFR47 Part 15, EN55024, EN55032
|
|
EMS:
IEC61000-4-2(ESD) ± 6kV(contact), ±8kV(air)
IEC61000-4-3(RS) 10V/m(80MHz~2GHz)
IEC61000-4-4(EFT) Power Port: ±2kV; Data Port: ±1kV
IEC61000-4-5(Surge) Power Port: ±1kV/DM, ±2kV/CM
IEC61000-4-6(CS) 10V(150kHz~80MHz)
|
|
Immunity:
IEC60068-2-6(Vibration)
IEC60068-2-27(Impact)
IEC60068-2-32(Free Fall)
|
Industrial IP67 Waterproof PoE Injector Ordering Information
|
Model
|
Description
|
|
LNK-IPOE-95W
|
95W Outdoor Industrial IP67 Waterproof 802.3bt PoE+ Injector
|
|
Mounting Options
|
► Pole-mounted (installation kit needs to be purchased separately)
|
|
LNK-POT-MBK
|
Pole-Mount installation kit
|
Industrial IP67 Waterproof PoE Injector Application
After-Sales and Warranty Policy
It is composed of online customer service and telephone customer service, providing
product consultation, remote technical support, maintenance and acceptance services.
Service Policy: Three-month replacement and three-year warranty.
Replacement: Within three months of purchasing a series of products, after testing the product failure
by technicians and man-made damage caused by non-natural disasters, the purchaser can directly
go to the purchasing point to replace the same type of products.Or a product of comparable performance.
If there is no trouble in product testing, the original sample will be returned.
Warranty: Man-made damage caused by non-natural disasters, our company's free warranty period is 1 year.
[The following circumstances do not fall within the scope of replacement and free maintenance]
1.Damage caused by operation and maintenance not in accordance with the instructions in the product manual.
2.Damage caused by human factors, such as inappropriate voltage input, water intake and breakage.
3.Damage to products caused by natural disasters, such as lightning, earthquakes, fires, etc.
3.Unauthorized alteration of the inherent settings or repair without the company's permission.
4.Products beyond the scope of free maintenance.
5.Damage caused by transportation, loading and unloading during repairs sent by customers.
6.The product bar code or model on the product warranty card does not conform to the product itself.
7.Failure or damage caused by other non-product problems such as design, technology, manufacturing and quality.
