Industrial 10G PoE+ Injector 60W High Power 12–48VDC Wide Input

Large Image : Industrial 10G PoE+ Injector 60W High Power 12–48VDC Wide Input

Product Details:

Place of Origin:	Shenzhen, China
Brand Name:	E-link
Certification:	ISO9001, CE, RoHS, FCC
Model Number:	LNK-INJ601-60

Payment & Shipping Terms:

Minimum Order Quantity:	1PCS
Price:	$68-$78
Packaging Details:	PoE Injector Standard export package
Delivery Time:	3-5 working days
Payment Terms:	T/T, Western Union, MoneyGram, Paypal
Supply Ability:	1000pcs/Month

Contact Now

Detailed Product Description

Certifications:	ISO9001, FCC Part 15 Class A, CE EN55022	Operating Temp:	-40°C To +80°C, MTBF >200,000 Hrs
Power Input:	12–48VDC, Max. 65W	Enclosure:	Aluminum Alloy, 95 × 70 × 30 Mm, 0.25Kg
Data Rate:	10/100/1000/2.5G/5G/10G Base-T	PoE Standard:	IEEE 802.3af/at (PoE/PoE+)

Industrial 10G PoE+ Injector 60W High Power 12–48VDC Wide Input

Overview

The LNK-INJ601-60 is a high-performance 10G industrial PoE+ injector designed to power network

devices such as IP cameras, access points, and IoT equipment. Delivering up to 60W PoE output, it

ensures stable connectivity for high-bandwidth applications. With 12–48VDC wide-range input, compact

aluminum housing, and an operating range of -40°C to +80°C, it provides reliability in harsh industrial

environments.

Features

10G Ultra-Speed Support – Compatible with 10/100/1000/2.5G/5G/10G Base-T.

High-Power PoE+ Output – Supplies up to 60W per port (IEEE 802.3af/at).

Wide Input Range – Operates on 12–48VDC with low power consumption.

Compact & Rugged – Aluminum alloy case, 95 × 70 × 30 mm, lightweight design.

Industrial-Grade Build – Reliable in -40°C to +80°C extreme climates.

Plug-and-Play – Easy deployment with DIN-rail and wall-mount installation.

Clear Status Monitoring – LED indicators for power and PoE diagnostics.

Technical Indexes

Ethernet
Standards:	IEEE802.3af Power over Ethernet
Standards:	IEEE802.3at Power over Ethernet
Processing Type:	Forward
Processing Type:	Half-duplex, Full-duplex
Forward Filter Rate:	14,880,000pps (10Gbps)
Cabling:	10/100/1000/2.5G/5G/10G Base-T: Cat7 or above
Maximum Distance:	Cat7 UTP up to 30m
Connector:	2x RJ45
Environmental
Operating Temperature:	-40°C to 80°C (-40°F to 176°F)
Storage Temperature:	-40°C to 85°C (-40°F to 185°F)
Relative Humidity:	5% to 95% non-condensing
MTBF:	>200,000hrs
Electrical and Mechanical
Input Power:	12~48VDC (Terminal Block)
Power Consumption:	65W Max.
PoE (Power over Ethernet)
Standard:	IEEE802.3af/at
Port:	RJ45
Power Pin Assignment	4/5(+), 7/8(-)
Max. Power per Port:	60W Max per port (Alternative B Mode)
LED Indicators:
Power:	Power Status
PoE:	PoE Status
Dimensions (WxDxH):	95 x 70 x 30 mm
Weight:	0.25Kg
Casing:	Aluminum Case
Mounting Options:	DIN-Rail / Wall-mount
Regulatory Approvals
ISO9001
FCC part 15, Class A
EN55022:2006+A1: 2007 Class A
Surge Protection:
RJ45: 1KV
Power: 500V
ESD: 4KV/8KV

Ordering Information

Model	Description
LNK-INJ601-60	12~48VDC Power Input Industrial 10G 60W PoE Injector
Mounting Options	► Default DIN-Rail Bracket installed; Wall Mount Bracket is included.
Power Options	► Power Supply is to be purchased separately
