Mini Industrial 8-Port 10/100/1000T 802.3at PoE + 2-Port 10/100/1000T Compact Ethernet Switch
Mini Industrial 10-Port Ethernet Switch Overview
The LNK-IMC010GP represents a high-density industrial networking solution, integrating eight 802.3at PoE+ Gigabit ports and two additional uplink interfaces within a compact form factor specifically engineered for space-constrained installations. Delivering substantial 240-watt total PoE budget, this robust switch enables simultaneous operation of multiple high-power devices including PTZ cameras, wireless access points, and industrial sensors while maintaining wire-speed data transmission. Its advanced power management system supports 48-57V DC redundant input configuration, ensuring continuous operation even during power fluctuations commonly encountered in industrial settings.
Manufactured with industrial-grade components and housed in a fanless IP40-rated metal enclosure, the switch demonstrates exceptional resilience against electromagnetic interference, power surges, and mechanical vibrations. The optimized thermal design eliminates moving parts while maintaining stable performance across extreme temperatures from -40°C to 80°C, making it suitable for deployment in uncontrolled environments such as manufacturing floors, transportation corridors, and outdoor surveillance points. Compliant with IEEE 802.3at PoE+ standards, each powered port delivers up to 30W for flexible connectivity of energy-demanding equipment without requiring additional electrical infrastructure. This unmanaged switch offers immediate deployment capability for industrial automation, smart city infrastructure, and critical communication networks where reliability and space efficiency are paramount considerations.
Mini Industrial 10-Port Ethernet Switch Features
- High-Density Gigabit Connectivity - Integrates ten 10/100/1000BASE-T RJ45 interfaces, including eight PoE-enabled ports and two dedicated uplink connections for flexible network architecture
- Dual Standard PoE Compatibility - Supports both IEEE 802.3af and 802.3at powered devices, automatically detecting and delivering appropriate power levels to connected equipment
- Advanced Power Redundancy System - Implements 48-57V DC dual power input with reverse polarity protection, ensuring continuous operation during power source switching or connection errors
- Intelligent Traffic Management - Incorporates 802.3x flow control mechanism to prevent data packet loss and maintain network stability during high-bandwidth transmission periods
- Energy Efficient Operation - Complies with IEEE 802.3az EEE standards, reducing power consumption by up to 70% during low-data activity while maintaining network responsiveness
- Industrial Mounting Flexibility - Features DIN-rail mounting compatibility for seamless integration into standard industrial control panels and automation cabinets
- Enhanced Mechanical Protection - Constructed with heavy-gauge steel housing and IP40-rated sealing, providing superior dust resistance and mechanical durability in challenging environments
- Extended Thermal Performance - Maintains full operational stability across -40°C to 80°C temperature range without requiring active cooling, suitable for both extreme cold and high-heat applications
- Simplified Network Deployment - Offers plug-and-play installation with automatic device detection and configuration, eliminating the need for specialized technical knowledge
Mini Industrial 10-Port Ethernet Switch Dimension & Size
Mini Industrial 10-Port Ethernet Switch Technical Indexes
| Ethernet |
| Standards: |
IEEE 802.3 Ethernet |
| IEEE 802.3u Fast Ethernet |
| IEEE 802.3ab Gigabit Ethernet |
| IEEE 802.3x Full-Duplex Flow Control |
| IEEE 802.3az Energy Efficient Ethernet (EEE) |
| Forward & Filtering Rate: |
14,880pps (10Mbps) |
| 148,800pps (100Mbps) |
| 1,488,000pps (1000Mbps) |
| Packet Buffer: |
2Mbits |
| Packet Length: |
9216bytes |
| MAC Address Table: |
4K entries |
| Switch Fabric: |
20Gbps/non-blocking |
| Switch Throughput (packet per second) |
14.88Mpps@64bytes |
| Interface |
| Connector: |
10 10/100/1000BASET RJ45 auto-MDI/MDI-X ports
8 ports with 802.3at PoE+ injector function (Port 1 to 8)
|
| PoE (Power over Ethernet) |
| Standard: |
IEEE 802.3at Power over Ethernet Plus/PSE
IEEE 802.3af Power over Ethernet/PSE
|
| Port: |
RJ45 |
| Power Pin Assignment |
4/5(+), 7/8(-) |
| PoE Budget: |
Up to 240-watt PoE budget |
| Max. Number of Class 4 PDs |
8 |
| Environmental |
| Operating Temperature: |
-40°C to 80°C (-40°F to 176°F) |
| Storage Temperature: |
-40°C to 85°C (-40°F to 185°F) |
| Relative Humidity: |
5% to 95% non-condensing |
| MTBF |
> 100,000 hrs |
| Electrical and Mechanical |
| Input Power: |
48~57VDC
Redundant power with polarity reverses protection function
|
| Power Consumption: |
<250W (Non-PoE<10W) |
| Power Input Overload: |
Automatic Resettable |
| Reverse Polarity: |
Present |
| Dimensions (WxDxH): |
95 x 88 x 46mm |
| Weight: |
400g |
| Casing: |
Aluminum Case |
| Mounting Options: |
DIN-Rail mount |
| LED Indicators: |
| PWR |
Power |
| L/A |
Link/Activity |
| SPD |
Data Rate |
| PoE |
Max 30W per port |
| Regulatory Approvals |
| EMC |
CE (EN55032, EN55035) |
| EMI |
FCC Part 15 Subpart B |
| EMS |
EN61000-4-2 (ESD) EN61000-4-3 (RS) |
| EN61000-4-4 (EFT) EN61000-4-5 (Surge) |
| EN61000-4-6 (CS) EN61000-4-8 (PFMF) EN61000-4-11 |
| Safety |
CE (EN60950-1) |
| Surge Protection |
8KV for PoE, RJ-45 and SFP ports |
| Shock |
IEC60068-2-27 |
| Freefall |
IEC60068-2-32 |
| Vibration |
IEC60068-2-6 |
Mini Industrial 10-Port Ethernet Switch Ordering Information
| Model |
Description |
| LNK-IMC010GP |
Mini Industrial 8-Port 10/100/1000T 802.3at PoE + 2-Port 10/100/1000T Compact Ethernet Switch |
| Mounting Options |
► Default DIN-Rail Bracket installed. |
| Power Options |
► Power Supply is to be purchased separately |
Mini Industrial 10-Port Ethernet Switch Application
Industrial Automation Networks - Provides deterministic connectivity for machine vision systems, PLC controllers, motor drives and HMI panels in automotive manufacturing and process control facilities, with vibration resistance ensuring signal integrity
• Intelligent Transportation Systems - Enables traffic monitoring cameras, variable message signs, and vehicle detection sensors deployment along highways and intersections, maintaining operation through extreme weather conditions
• Energy Infrastructure Monitoring - Supports remote terminal units, power quality meters, and condition monitoring equipment in substations and renewable energy farms with wide voltage input compatibility
• Urban Security Deployments - Powers multi-camera surveillance networks, access control systems, and perimeter detection devices across smart city applications using 240W PoE+ functionality
• Rail and Mass Transit Communications - Facilitates passenger information displays, onboard CCTV systems, and station security equipment with ruggedized construction for rolling stock applications
