| Keywords: | 10 Port Industrial Ethernet Switch | Input Power: | 12~48VDC Wide Range Power |
|---|---|---|---|
| Casing: | Aluminum Case | Mounting Options: | DIN-Rail / Wall-mount |
| Dimensions: | 95 X 88 X 46mm | Weight: | 0.3Kg |
| High Light: | unmanaged Gigabit Ethernet Switch,Aluminum Case Gigabit Ethernet Switch,48VDC compact gigabit switch |
||
Network Switch Mini Industrial 10-Port 10/100/1000T Gigabit Compact Ethernet Switch
10-Port Gigabit Network Switch Advantages
► 10-port 10/100/1000BASE-T RJ45 with auto-MDI/MDI-X function
► Supports auto-negotiation and 10/100Mbps half/full duplex and 1000Mbps full duplex
► 12~48VDC wide range power input
► Industry standard design, dustproof and close design IP40, rugged high-strength metal case
Technical Indexes
| Forward & Filtering Rate: | 14,880pps (10Mbps) |
| 148,800pps (100Mbps) | |
| 1,488,000pps (1000Mbps) | |
| Packet Buffer: | 2Mbits |
| Packet Length: | 9216bytes |
| MAC Address Table: | 4K entries |
| Switch Fabric: | 20Gbps/non-blocking |
| Switch Throughput (packet per second) | 14.88Mpps@64bytes |
| Connector: | 10 x 10/100/1000BASE-T RJ45 auto-MDI/MDI-X ports |
| Input Power: |
12~48VDC Redundant power with polarity reverses protection function |
| Power Consumption: | <10W |
| Power Input Overload: | Automatic Resettable |
| Reverse Polarity: | Present |
| LED Indicators: | |
| PWR | Power |
| L/A | Link/Activity |
| SPD | Data Rate |
Overview
LNK-IMC010G Series is a Mini Industrial 10-Port 10/100/1000T Gigabit Ethernet Switch with 12~48VDC wide range power input. This unmanaged industrial Ethernet switch is designed to match the critical industrial standards. With reliable and simple operation against vibration and shock, and wide operation temperature range, it could match a variety of harsh environment. The switch complies with CE and FCC standards, and passed the 100% burning test to ensure that it will fulfill the needs of industrial applications. It is a good choice for an economical solution for industrial Ethernet connections.
Ordering Information
| Model | Description |
| LNK-IMC010G | Mini Industrial 10-Port 10/100/1000T Gigabit Ethernet Switch |
| Mounting Options | ► Default DIN-Rail Bracket installed; Wall Mount Bracket is included. |
| Power Options | ► Power Supply is to be purchased separately |
