IEEE 802.3af / at Fiber Optic Cable Ethernet Converter Steadily Work Capability

China IEEE 802.3af / at Fiber Optic Cable Ethernet Converter Steadily Work Capability supplier

Large Image :  IEEE 802.3af / at Fiber Optic Cable Ethernet Converter Steadily Work Capability

Product Details:

Place of Origin: China
Brand Name: E-link
Certification: RoHS,CE,FCC
Model Number: LNK-GYP001 Series

Payment & Shipping Terms:

Minimum Order Quantity: 1
Price: Negotiation
Packaging Details: Standard Export Package
Payment Terms: T/T, Western Union, L/C, D/P, D/A, MoneyGram,Paypal
Supply Ability: 10000 pieces /month
Contact Now
Detailed Product Description
Port: 1x10/100Base-T RJ45 Fiber Ports: SC/ST/FC/LC/SFP Connector, Optional
Dimensions: 61 X 120 X 140 Mm Wavelength: 850nm, 1310nm, 1550nm
Input Voltage: 48V DC (46~50VDC Weight: 730g
Operating Temperature: -40°C To +80°C Installation: DIN-Rail Or Wall Mounting



IEEE 802.3af / at Fiber Optic Cable Ethernet Converter Steadily Work Capability



Model: LNK-GYP001 Series



Overview



LNK-GYP001 series Industrial Ethernet-to-fiber media converters provide 1-port Ethernet media conversion from 10/100BaseT(X) to 100BaseFX (with FC, SC, ST or SFP connectors).



These switches are classified as power source equipment (PSE), and when used in this way provide up to 15.4 watts to IEEE 802.3af (or 25.5 watts to IEEE 802.3at) compliant powered devices (PDs), eliminating the need for additional wiring.



The LNK-GYP001 converters support IEEE 802.3/802.3u/802.3x with 10/100M, full/half-duplex, and MDI/MDI-X auto-sensing, providing a complete solution for your industrial Ethernet network.



In addition, the built-in relay warning function alerts network engineers when power failures or port breaks occur.



Technical Indexes



Parameter Specifications
Standard

IEEE 802.3 for 10Base-T

IEEE 802.3u for 100Base-TX and 100Base-FX (Fast-Ethernet)

IEEE 802.3x for Flow control

IEEE 802.3af PoE specification (up to 15.4 Watts per port for P.S.E.)

IEEE 802.3at PoE specification (up to 25.5 Watts per port for P.S.E.)

RJ45 Port 1x10/100Base-T, Auto-negotiation, Full/Half Duplex, Auto-MDI/MDIX, on copper cable of cat5 with operation distance of less than 100 meters.
Fiber Ports 1x100Base-FX ports (SC/ST/FC/LC/SFP connector, optional)
Transmission

Twisted pair: 100M (Standard CAT5/CAT5e cable)

Multi mode fiber: 1310nm, 2km

Single mode fiber: 1310nm, 20/40/60Km

1550nm, 20/40/60/80/100/120Km

Wavelength 850nm, 1310nm, 1550nm
Power Input options

Input Voltage: 48V DC (46~50VDC) ,Redundant power input

Overload Current Protection

Support dual power backup

Support dual power alarm input

Connection: 6 pin terminal

Environmental Limits

Operating Temperature: -40°C to +80°C

Storage Temperature: -45°C to +85°C

Relative Humidity: 5% to 95% (non-condensing)

Mechanical Dimension

Dimensions: 61 x 120 x 140 mm

House Protection: IP40 protection, Aluminium Alloy

Installation: DIN-Rail or wall mounting

Weight: 730g

Approvals

EMI: FCC Part 15 Subpart B Class A,EN 55022 Class A

EMS:

• EN61000-4-2 (ESD) , Level 3

• EN61000-4-3 (RS) , Level 3

• EN61000-4-4 (EFT) , Level 3

• EN61000-4-5 (Surge), Level 3

• EN61000-4-6 (CS) , Level 3

• EN61000-4-8, Level 3

Shock: IEC 60068-2-27

Free Fall: IEC 60068-2-32

Vibration: IEC 60068-2-6



Features

  • Comply to IEE 802.3 10Base-T,IEEE802.3u ,100Base-TX/FX, 1000Base-TX/FX
  • Provide a singlemode /multimode optical port and 10/100M RJ45 port, support for Full/half duplex mode and auto MDI/MDI-X connection
  • Comply to IEEE 802.3af/at, provide power for the IP cameras over Ethernet
  • Dynamic LED indicator, display the current operating status, providing a simple working condition and troubleshooting tips
  • Adopt IEEE 802.3x Standard full-duplex flow control ,with standard duplex Backpressure flow control
  • -40℃ to 80℃operating temperature range
  • Designed for industrial applications. IP40 protection, Aluminum Alloy
